Trailers

Ironmann Industries trailer and supply company. We manufacture and custom build trailers to you specification.

Shipped in 1-2 Business Days.

  1. Trailer plains available for each model.
  2. Trailer axle kits includes everything except mainframe steel.
  3. Trailer steel kits includes precut main frame steel, Trailer kits plus Trailer plains.

Delivery to Any 48 States!

Untitled-30
Discription
2 5200# Axle wyBrakes, hub Bearing, lugs & nuts
2 U-Bolt kit, Rd, 3”*7”*5625”=18 wy U-Bolts, Plates, Washers $ Nuts, Boxed
1 Hanger kit, Tndm, Dbl Eye, 3.5-7K, Boxed
4 Spring, Dbl Eye, 1.75”, 2.9K, 5 Lf, 25.25” I To I, 3”Arch, 5625” Eye
2 Fend, Tndm W/D 10.75W 072.00L 096,00 1” RF 20.50H 19.25R 16 Ga CR
2 Back, Fender, Pre-Cut, 12”*69.25”16Ga, Fits 72”
1 Coupler, 2-5/16” Ball, A-Frm, 12.5K Cap, Low Latch
1 Chain, Safety, 25*54”, 5.2K Cap wy 2 Hooks
1 ack Swvl Pipe Sw 5K Cap, 10” Lift wy Mntg Pipe & Fixed Foot
4 Light Kit, Sealed Tail, Obing, Flush Mnt, Red wy Light, Grommet & Plug
2 Light Kit, Sealed Turn, Rnd, Flush Mnt, Amber wy, Grommet & Plug
1 Light, Sealed, ID-Bar, Rect, Red
1 Connector, 6-Way, Rnd Plug (Pollak)
26’ Cable, Lighting, 6 Wire, 14 Ga-6 (Foot)
Untitled-1

<

1Free Delivery to Any 48 States!

Untitled-30
Description
2 3500# Electric Brake Axle wyhub, Bearing, lugs & nuts
1 Hanger Kit, Tndm, Dbl Eye, 3.5-7K, Boxed
2 U-Bolt Kit, Rd, 2.375”*5.5*5”- 20 wy U-Bolts, Plates, Washer $ Nuts, Boxed
4 Spring, Dbl Eye, 1.75”, 1.75K, 4Lf, 25.25” I To I, 3” Arch, 5625” Eye
2 Fend, Tndm W/D 09.00W 072 00L 096.00 1” RF 20.50H 19.25R 16Ga CR
1 Coupler, 2” Ball, A-Frm, 7K Cap, LowLatch
1 Chain, Safety, 25*54”, 5.2K Cap wy 2 Hooks
1 Jack, A-Frm, Tw, 5K Cap, 14” Lift, 11’ H Brkt
1 Light, Tail, Sq, Stud Mnt W/ Side Marker, Red, Rh
1 Light, Tail, Sq, Stud Mnt W/ Side Marker, Red, Lh
2 Light, Clmc, Rect, Stud, Mnt, Amber
1 Connector, 6- Way, Rnd Plug (Pollack)
24′ Cable, Lighting, 6 Wire, 14Ga-6 (Foot)
4 Wheel $ Tire Mounted, 15”, ST205/75D15 C, 550 Wht Spk, 1.82K Cap

19’x82” Hydraulic Car Carrier Model

Untitled-30
Description
Bed Size: 19”*82”
Gross Capacity: 10,400 Ibs
Empty Weight: 2563 Ibs
Empty Tongue Weight: 557 Ibs
Frame: 5” Channel Steel
Deck: Diamond Plate
Features: Hydraulic Tilt Car Hauler, 2-5/16” Ball A- Frame Coupler, Tandem 5200Ib axles with leaf spring suspension, brakes on both axles, pivot tongue tilt, 3”*12” cylinder and 12 volt DC pump. No ramps required, 82” between fenders 19’ long bed, Steel deck. Commercial Design Easy Load!

18’x 8’ Car Carrier

Untitled-31
Description
Bed Size: 18”*80”
Gross Capacity: 7000 Ibs or 10,400 Ibs
Empty Weight: 2400 Ibs
Empty Tongue Weight: 328 Ibs
Frame: 5” Channel Steel
Deck: Diamond Plate
Features: 2” ball coupler, side wind jack, tandem 3500lb or 5200lb axles w/leaf spring suspension, slight dove-tall with ramps for easy loading, tie down D-rings with tool storage box, front square tubing bump rail, designed to meet state max. width of 102”. Professional Car Hauling Rig!!

16’x102″ Flat Deck Trailer

Untitled-32
Description
Bed Size: 16’x102″
Gross Capacity: 7000 Ibs or 10,400 Ibs
Empty Weight: 2500 Ibs
Empty Tongue Weight: 315 Ibs
Frame: Square Tube and Chennel
Deck: Diamond Plate
Features: 2” ball coupler, side wind jack, tandem 3500lb or 5200lb axles w/leaf spring suspension, Chain rails run down each side of the deck front security frame made of square tubung.

14’x6’4″ Hydraulic Dump Trailer

Untitled-33
Description
Box Size: 14’x6’4″w/3″
Bed Capacity: 9+ Cubic yards
Gross Capacity: 12,000 lbs
Empty Weight: 3560 Ibs
Empty Tongue Weight: 303 Ibs
Frame: 2″x6″ Rectangular
Upper Rim: Angle Steel, 11ga
Features: 2-5/16″ ball coupler, top wind jack tandem 6000lb axel w/leaf spring suspension, or torsion option, Hydraulic power package: 12 volt DC motor and a 2000psi pump, Hydraulic Scissor Lift. This is one rugged dump trailer!!!

12’x6’4″ Hydraulic Dump Trailer

Untitled-34
Description
Box Size: 12’x6’4″ w/3 sides
Bed Capacity: 8+ Cubic yards
Gross Capacity: 12,000 lbs
Empty Weight: 3450 Ibs
Empty Tongue Weight: 300 Ibs
Frame: 2″x6″ Rectangular Tubing
Upper Rim: Angle Steel, 11ga
Features: 2-5/16″ ball coupler, top wind jack tandem 6000lb axel w/leaf spring suspension, or torsion option, Hydraulic power package: 12 volt DC motor and a 2000psi pump, Hydraulic Scissor Lift. Serious dump trailer!!!

11’2″x6′ Two Horse Trailer

Untitled-35
Description
Box Size: 12’x6’x86″ ht.
Gross Capacity: 7,000 lbs
Empty Weight: 2420 Ibs
Empty Tongue Weight: 283 Ibs
Frame: 2″x4″ 11ga Rectangular Tubing
Deck: 3/4″ Plywood
Features: 2″ ball coupler, top wind jack, tandem 3500lb axles w/ leaf spring or torsion suspension, 3″ tack and hay compartment with lockable doors, two rear doors with removable center divider, cowboy walk-through doors (22″) on each front, and steel or aluminum skin.

12’x6’6″ Utility Trailer

Untitled-36
Description
Box Size: 12’x6’6″
Gross Capacity: 3500 lbs or 5200 lbs
Empty Weight: 1525 Ibs
Empty Tongue Weight: 175 Ibs
Frame: Angle Steel
Deck: Wood
Features: 3500 lbs or 5200 lbs Single Axle Option, 2″ ball coupler, top wind jack,rear and side fold down ramps or conventional rear tailgate, single axle w/leaf spring suspension. Designed for ATV’s, camping, lawn & garden and sporting equipment. A Heavey-Duty Trailer, Rugged Design.

10’x5′ Hydraulic Dump Trailer

Untitled-37
Description
Box Size: 10’x5′
Bed Capacity: 2 Cubic Yards
Gross Capacity: 7000lbs
Empty Weight: 1830 Ibs
Empty Tongue Weight: 375 Ibs
Frame: Chennel Steel
Upper Rim: Angle Steel and 14ga Metal Sheeting
Features: 2″ ball coupler, top wind jack, tandem 3500lb axle w/leaf spring suspension Hydraulic power package: 12 volt DC motor and a 2500psi pump, single 4″x30″ cylinder. Hydraulic lift kits can be adapted to the trailer and dump bed. This is one rugged dump trailer!!!

10’*6’ Utility

Untitled-38
Description
Box Size: 10’*6’
Gross Capacity: 3500 Ibs
Empty Weight: 1180 Ibs
Empty Tongue Weight: 85 Ibs
Frame: Angle Steel
Deck: Wood
Features: 2” ball coupler, top wind jack, rear fold down tailgate w/ optional wooden tailgate, single axle w/leaf spring suspension, heavy duty design

10’x5’ Aluminum Bolt Together

Untitled-39
Description
Box Size: 10’x5’
Gross Capacity: 3500 lbs
Empty Weight: 508 lbs
Empty Tongue Weight: 110 lbs
Frame: Angle Aluminum or Steel
Deck: Diamond Plate or Wood
Features: 2” ball coupler, top wind jack, diamond plate tailgate with chain locks and supports, 14” or 15” wheels, torsion suspension. No Welding Required!!

10’x6’4” Utility

Untitled-40
Description
Box Size: 10’x6’4”
Gross Capacity: 3500 lbs
Empty Weight: 1180 lbs
Empty Tongue Weight: 85 lbs
Frame: Angle Steel
Deck: Wood
Features: 2” ball coupler, top wind jack, rear fold down removable tailgate w/optional wooden tailgate, single axle w/leaf spring suspension, heavy duty design

8’x 5’ Dump Bed Trailer

Untitled-41
Description
Box Size: 8’x5’
Bed Capacity: 2 Cubic Yards
Gross Capacity: 5200lbs or optional 3500 lbs
Empty Weight: 1311 lbs
Empty Tongue Weight: 220 lbs
Frame: Rectangular & Channel Steel
Upper Rim: Channel & Angle Steel and 14+ ga Metal Sheeting
Features: Single 5200 lb or 3500 lb Axle w/Leaf Spring Suspension, 2-5/16” or 2” Ball, Top Wind Jack, 5 Ton Scissor with Oil Hydraulics. Combination Rear Gate, One Tuff Trailer!!!

8’*5’ Utility

Untitled-42
Description
Box Size: 8’*5’
Gross Capacity: 2000-3500 lbs
Empty Weight: 615 lbs
Empty Tongue Weight: 85 lbs
Frame: Angle Steel
Dick: Wood
Features: 2” ball coupler, top wind jack, single axle w/leaf spring suspension, folding rear steel gate/ ramp combo w/ optional wooden tailgate, heavy duty design, proven towing ability. Great first time project!!

6’x’2” Utility Trailer

Untitled-43
Description
Box Size: 6’x4’2”
Gross Capacity: 2000 lbs
Empty Weight: 555 lbs
Empty Tongue Weight: 55 lbs
Frame: Angle Steel
Deck: Wood

8’x4’ Utility

Untitled-44
Description
Box Size: 8’x4’
Gross Capacity: 2000-3500 lbs
Empty Weight: 580 lbs
Empty Tongue Weight: 85 lbs
Frame: Angle Steel
Deck: Wood
Features: 2” ball coupler, top wind jack, single axle w/ leaf spring suspension, heavy duty design, proven towing ability. Great first time project!!!

4’x3’ Off- Road Utility Cart

Untitled-45
Description
Box Size: 4’x3’
Gross Capacity: 750 lbs
Empty Weight: 120 lbs
Empty Tongue Weight: 14 lbs
Frame: Angle Steel
Features: 2” ball coupler, square tubing axle with bearing spindles and knobby tires bolt together design.

Heavy Duty Car Dolly

Untitled-46
Description
Swivel Pan: 72” O.D- 40” I.D.
Gross Capacity: 3500 lbs
Empty Weight: 1050 lbs
Empty Tongue Weight: 90 lbs
Frame: Square Tubing
Features: 2” ball coupler, swivel table design w? pull out ramps, variable adjustment web ratcht slide

5’x102″ Gooseneck Flat Deck Trailer

Untitled-47
Description
Bed Size: 25’x102″
Gross Capacity: 20,000 lbs
Empty Weight: 8275 lbs
Empty Tongue Weight: 1080 lbs
Frame: I-Beam and Chennel
Deck: Diamond Plate or Wood
Features: 5′ dove tail, fold down ramps w/assist springs, adjustable coupler, dual side wind jack, chain and boomer storage between lower tongue members, and chain packets w/heavy rails along each side.

32’x102″ Gooseneck Flat Deck Trailer

Untitled-48
Description
Bed Size: 32’x102″
Gross Capacity: 24,000 lbs
Empty Weight: 8625 lbs
Empty Tongue Weight: 1945 lbs
Frame: I-Beam and Chennel
Deck: Diamond Plate or Wood
Features: 5′ dove tail, fold down ramps w/assist springs, adjustable coupler, dual side wind jack, chain and boomer storage between lower tongue members, and chain packets w/heavy rails along each side.

24’x6′ Livestock Trailer Model

Untitled-49
Description
Box Size: 24’x6′
Gross Capacity: 16,000 lbs
Empty Weight: 5900 lbs
Empty Tongue Weight: 1400 lbs
Frame: Pipe
Deck: Wood
Features: 5′ dove tail, fold down ramps w/assist springs, adjustable coupler, dual side wind jack, chain and boomer storage between lower tongue members, and chain packets w/heavy rails along each side.

26’x102″ Gooseneck Trailer Plans *As Seen On Xtreme 4×4*

Description
Box Size: 26’x102″
Gross Capacity: 14,000 lbs
Empty Weight: 4150 lbs
Empty Tongue Weight: 1730 lbs
Frame: Chennel & Ractangular Tubing
Deck: Diamond Plate or Wood
Features: 82″ Clearance between the fenders, Deck at 102″ in front and rear of the fenders, Heavy duty fenders, adjustable Coupler, Dual side Wind Jacks, Ramps with Rear Storage Pockets, and Chain Pockets w/heavy rails along each side.
